General
| In The Box |
- 1 Indoor Unit, 1 Outdoor Unit, User Manual, Warranty Card, Remote, Copper Pipe
|
| Brand |
|
| Model Name |
|
| Type |
|
| Capacity in Tons |
|
| Star Rating |
|
| BEE Rating Year |
|
| Color |
|
| Cooling Capacity |
|
| Compressor |
- Patented Swing Compressor
|
| Dehumidification |
|
| Remote Control |
|
| Refrigerant |
|
| Condenser Coil |
|
Dimensions
| Indoor W x H x D |
|
| Indoor Unit Weight |
|
| Outdoor W x H x D |
|
| Outdoor Unit Weight |
|
| Other Dimensions |
- Indoor Package Dimension (H x W x D) (mm): 375 x 980 x 325. Indoor Gross Weight: 13.5 kg. Outdoor Package Dimension (H x W x D) (mm): 680 x 1035 x 410. Outdoor Gross Weight: 35 kg.
|
Air Flow & Filter Features
| Other Air Flow Features |
- Air Throw: 16 m (52 Feet). Airflow Rate (CFM): 572. Airflow Rate (CMM): 16.2.
|
| Anti-bacteria Filter |
|
| Dust Filter |
|
| Other Filter Features |
|
Convenience Features
| Auto Restart |
|
| Other Convenience Features |
- Outdoor Unit Model: RKL50UV16V. Rated Cooling Capacity Full/Half (Min. – Max.) (kW): 5.0/2.5 (1.75 – 5.2). Rated Cooling Capacity Full/Half (Min. – Max.) (Btu/h): 17100/8550 (5970 – 17740). Cooling Capacity at 43 DegreeC: 100%. Voltage Range (Stabilizer Inside): 130 – 285 V. Operating Current: 7.41 A. Panel Color: White. Moisture Removal (l/hr): 1.6. Operation Sound H/MH/M/ML/L/SL (dBA): 46/43/41/38/35/32. Breaker Size: 20 A. Piping Length: Charge-less – 10 m, Max. Length – 20 m, Max. Height – 16 m. Piping Connection Gas / Liquid mm (inch): 12.7 / 6.4 (1/2 / 1/4). Operating Ambient Temperature Range Cooling (Min. – Max.) DegreeC DB: 20 – 52.
|
| Additional Features |
- The Hepta sensors play a vital role by continously sensing temperature change and working of critical components such as Compressor,PCB,motors or heat exchangers thus providing convenience and increases durability.
- Stabilizer Inside. Power-airflow Dual Flaps. Triple Display. 3D Airflow. Anti-corrosion Treatment. Automatic Error Code Display. Coanda Airflow. Cools at 52 DegreeC. Dew Clean Technology. Econo Mode. Good Sleep Off Timer. Power Chill Operation. Rated Power Consumption Half (Min. – Max.) (W): 554 (375 – 1750). Rated Annual Power Consumption (kWh): 966.47.
|
Power Features
| Power Requirement |
|
| Annual Electricity Consumption |
|
| Other Power Features |
- Rated Power Supply Phase: 1. Power Supply Intake: Outdoor Unit.
|
